AT-707 Auto Double Roll Cutting Machine

Features ofAT-707 Auto Double Roll Cutting Machine Easy to operate, controlling by Panel.The function of panel: A. Design the speed. B. LCD screen interface.Auto cutting without operating with the material.Double jumbo rolls be cutting together, Blade is controlled by the Oil cylinder.The blade could cut up and down, bro and back, right and left.The jumbo rolls is driving by Motor, Equipped with the precise Ball bearing and linearity gliding Obit, with excellent orientation.The operator just needs to put the Jumbo rolls on the frame for the laying material, Auto feed-in. MAIN TECHNICAL PARAMETERS:Length WidthMax. 1340mmSlitting width3-30mmRange of Cutting Width25-1350mmMaximum cut diameter80mmDiameter of pager tube25-44mmCutting Speed45-500 Roll/minDiameter of Blade100mm
